Can design and produce according to customer´s requirements, drawing or sample. OEM, ODM.
Model: WPL-A01 / WPL-A02
Material: Solid heavy-gauge steel, durable powder coated finish (colour: silver, black)
±15° rotation for optimal viewing angle, compatible all-hole patterns for easy and fast installation
Horizontal adjusting even after installation, with installation guide and hardware kit.
|
Model
|
H (mm)
|
W (mm)
|
For TV size
|
Max extension (mm)
|
|
WPL-A01
|
320
|
460
|
11” - 40”
|
400
|
|
WPL-A02
|
460
|
732
|
34” – 50”
|
670
|
Model: WPL-B01 / WPL-B02
Material: Solid heavy-gauge steel, durable powder coated finish (colour: silver, black)
180° rotation with ±10° tilt of swivel arms for optimal viewing angle, compatible all-hole patterns for easy and fast installation
Horizontal adjusting even after installation, with installation guide and hardware kit.
|
Model
|
H (mm)
|
W (mm)
|
For TV size
|
Max extension (mm)
|
|
WPL-B01
|
400
|
400
|
14” - 46”
|
400
|
|
WPL-B02
|
460
|
740
|
32” – 50”
|
700
|
Model: WSG-1437 Model: WSG-3250
Material: Cold-rolled steel Material: Cold-rolled steel
Size: 460 (L)×340 (W) mm Size: 730 (L)×460 (W) mm
Weight: 2.6KGS Weight: 4.4KGS
MAX. loading: 45KGS MAX. loading: 70KGS
For 14" - 37" LCD TV For: 32" - 50" LCD TV
Model: WSG-1324 Model: WSG-1324A
Material: Cold-rolled steel Material: Cold-rolled steel
Size: 100 (L)×80 (W) mm Size: 160 (L)×65 (W) mm
For 13" - 24" LCD TV For 13" - 24" LCD TV
Model: W212
Material: Stainless steel
Size: 54 (W)×75 (H) mm
General type for all |
